Iterator4D Class Reference
Implementation of Tensors of Rank 4. More...
#include <matpackIV.h>
Public Member Functions | |
| Iterator4D () | |
| Default constructor. | |
| Iterator4D (const Iterator4D &o) | |
| Copy constructor. | |
| Iterator4D (const Tensor3View &x, Index stride) | |
| Explicit constructor. | |
| Iterator4D & | operator++ () |
| Prefix increment operator. | |
| bool | operator!= (const Iterator4D &other) const |
| Not equal operator, needed for algorithms like copy. | |
| Tensor3View * | operator-> () |
| The -> operator is needed, so that we can write i->begin() to get the 3D iterators. | |
| Tensor3View & | operator* () |
| Dereferencing. | |
Private Attributes | |
| Tensor3View | msv |
| Current position. | |
| Index | mstride |
| Stride. | |
Detailed Description
Implementation of Tensors of Rank 4.Based on Tensor3 by Stefan Buehler.
The four dimensions are called: book, page, row, column.
- Date:
- 2002-03-01 The outermost iterator class for rank 4 tensors. This takes into account the defined strided.
Definition at line 38 of file matpackIV.h.
Constructor & Destructor Documentation
| Iterator4D::Iterator4D | ( | ) | [inline] |
| Iterator4D::Iterator4D | ( | const Iterator4D & | o | ) | [inline] |
| Iterator4D::Iterator4D | ( | const Tensor3View & | x, | |
| Index | stride | |||
| ) | [inline] |
Member Function Documentation
| Iterator4D& Iterator4D::operator++ | ( | ) | [inline] |
Prefix increment operator.
Definition at line 55 of file matpackIV.h.
References ConstTensor3View::mdata, mstride, and msv.
| bool Iterator4D::operator!= | ( | const Iterator4D & | other | ) | const [inline] |
Not equal operator, needed for algorithms like copy.
Definition at line 58 of file matpackIV.h.
References ConstTensor3View::mcr, ConstTensor3View::mdata, ConstTensor3View::mpr, ConstTensor3View::mrr, Range::mstart, and msv.
| Tensor3View * Iterator4D::operator-> | ( | ) |
The -> operator is needed, so that we can write i->begin() to get the 3D iterators.
Definition at line 30 of file matpackIV.cc.
References msv.
| Tensor3View & Iterator4D::operator* | ( | ) |
Member Data Documentation
Tensor3View Iterator4D::msv [private] |
Current position.
Definition at line 78 of file matpackIV.h.
Referenced by operator!=(), operator*(), operator++(), and operator->().
Index Iterator4D::mstride [private] |
The documentation for this class was generated from the following files:
